Stainless Steel-Cabinet "U" Handles / GN 425

Stainless Steel-Cabinet "U" Handles / GN 425
  • Promotional pricing ends 30/11/2024
  • Volume Discount

GANTER

GANTER

Stainless Steel-Cabinet "U" handles GN 425 Ø 6, Ø 8 and Ø 10 are supplied with two stainless steel location discs. They guarantee a perfect location even with large holes in the cabinet. The discs are loosely enclosed.

The manufacturing process (bending) allows the production of special lengths in relatively small quantities.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

GN 425 / Cabinet "U" Handles, Stainless Steel

Information


Stainless Steel-Cabinet "U" handles GN 425 Ø 6, Ø 8 and Ø 10 are supplied with two stainless steel location discs. They guarantee a perfect location even with large holes in the cabinet. The discs are loosely enclosed.
The manufacturing process (bending) allows the production of special lengths in relatively small quantities.

see also...
• Cabinet "U" handles GN 425.1 (Aluminum / Stainless Steel, angled)
• Cabinet "U" handles GN 427 (Aluminum / Stainless Steel, ellipse shaped profile)
• Stainless Steel-Cabinet "U" handles GN 565.5 (ellipse shaped profile)

How to Order

How to order (Stainless Steel)
1Material
2d1
3Length l
4Finish

Specification

• Stainless Steel                                        NI
  - AISI 303 (A2) for d1 = 8, 10
   AISI 304 (A2) for d1 = 12, 16
  - Matt shot-blasted                                           GS
  - Electropolished                                              EP
• Stainless Steel
  AISI 316L                                                A4
  Matt shot-blasted                                             GS
• Location discs
  - Stainless Steel, AISI 303 (for NI)
  - Stainless Steel, AISI 316L (for A4)
• Stainless Steel characteristics
• Load rating information
• RoHS compliant

On Request

• Stainless Steel version A4 electropolished

Dimensions


d1 Length l ±0.5      d2d3hrt min.
NIA4
6-3245556488--M 392677
8-55*6488*96100120*128M 41235108
101088*100120*180200235*-M 515431212
12-125160200250---M 6-511412
16-160200250300---M 6-591812
* suitable for 19“ rack and enclosure layout
Data to be displayed
30
45
60
  1. 1
Part Number
425-A4-10-88-GS
425-A4-10-100-GS
425-A4-10-120-GS
425-A4-10-180-GS
425-A4-10-200-GS
425-A4-10-235-GS
425-NI-6-32-EP
425-NI-6-32-GS
425-NI-6-45-EP
425-NI-6-45-GS
425-NI-6-55-EP
425-NI-6-55-GS
425-NI-6-64-EP
425-NI-6-64-GS
425-NI-6-88-EP
425-NI-6-88-GS
425-NI-8-55-EP
425-NI-8-55-GS
425-NI-8-64-EP
425-NI-8-64-GS
425-NI-8-88-EP
425-NI-8-88-GS
425-NI-8-96-EP
425-NI-8-96-GS
425-NI-8-100-EP
425-NI-8-100-GS
425-NI-8-120-EP
425-NI-8-120-GS
425-NI-8-128-EP
425-NI-8-128-GS
425-NI-10-88-EP
425-NI-10-88-GS
425-NI-10-100-EP
425-NI-10-100-GS
425-NI-10-120-EP
425-NI-10-120-GS
425-NI-10-180-EP
425-NI-10-180-GS
425-NI-10-200-EP
425-NI-10-200-GS
425-NI-10-235-EP
425-NI-10-235-GS
425-NI-12-125-EP
425-NI-12-125-GS
425-NI-12-160-EP
425-NI-12-160-GS
425-NI-12-200-EP
425-NI-12-200-GS
425-NI-12-250-EP
425-NI-12-250-GS
425-NI-16-160-EP
425-NI-16-160-GS
425-NI-16-200-EP
425-NI-16-200-GS
425-NI-16-250-EP
425-NI-16-250-GS
425-NI-16-300-EP
425-NI-16-300-GS
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Material Handle diameter d
(mm) 		Length l/l1
(mm) 		Finish

12.84 €

1 Available 4 Days [Stainless Steel] A4-Stainless Steel1088GS, matte shot-blasted

13.24 €

1 Available 7 Days [Stainless Steel] A4-Stainless Steel10100GS, matte shot-blasted

13.48 €

1 Available 7 Days [Stainless Steel] A4-Stainless Steel10120GS, matte shot-blasted

14.82 €

10.37 €

1 Available Same day

Stock

[Stainless Steel] A4-Stainless Steel10180GS, matte shot-blasted

15.36 €

10.75 €

1 Available Same day

Stock

[Stainless Steel] A4-Stainless Steel10200GS, matte shot-blasted

15.24 €

10.67 €

1 Available Same day

Stock

[Stainless Steel] A4-Stainless Steel10235GS, matte shot-blasted

9.58 €

6.71 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel632EP, electropolished

7.06 €

1 Available 3 Days [Stainless Steel] NI-Stainless Steel632GS, matte shot-blasted

9.80 €

6.86 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel645EP, electropolished

7.10 €

4.97 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel645GS, matte shot-blasted

10.00 €

7.00 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel655EP, electropolished

7.16 €

5.01 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel655GS, matte shot-blasted

10.82 €

7.57 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel664EP, electropolished

7.28 €

5.10 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel664GS, matte shot-blasted

10.30 €

7.21 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel688EP, electropolished

6.70 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel688GS, matte shot-blasted

9.44 €

6.61 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel855EP, electropolished

6.92 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel855GS, matte shot-blasted

9.62 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel864EP, electropolished

6.70 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel864GS, matte shot-blasted

10.34 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel888EP, electropolished

6.72 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel888GS, matte shot-blasted

10.52 €

7.36 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel896EP, electropolished

7.52 €

1 Available 3 Days [Stainless Steel] NI-Stainless Steel896GS, matte shot-blasted

10.64 €

7.45 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel8100EP, electropolished

6.96 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel8100GS, matte shot-blasted

10.78 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel8120EP, electropolished

7.22 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel8120GS, matte shot-blasted

11.02 €

7.71 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel8128EP, electropolished

7.56 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel8128GS, matte shot-blasted

13.00 €

9.10 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel1088EP, electropolished

8.12 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel1088GS, matte shot-blasted

13.30 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel10100EP, electropolished

8.66 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel10100GS, matte shot-blasted

13.42 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel10120EP, electropolished

8.72 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel10120GS, matte shot-blasted

14.52 €

1 Available 3 Days [Stainless Steel] NI-Stainless Steel10180EP, electropolished

9.86 €

6.90 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel10180GS, matte shot-blasted

14.98 €

10.49 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel10200EP, electropolished

10.48 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel10200GS, matte shot-blasted

17.50 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel10235EP, electropolished

11.18 €

7.83 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel10235GS, matte shot-blasted

14.34 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel12125EP, electropolished

11.26 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel12125GS, matte shot-blasted

16.14 €

11.30 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel12160EP, electropolished

12.70 €

8.89 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel12160GS, matte shot-blasted

17.40 €

12.18 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel12200EP, electropolished

14.14 €

9.90 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel12200GS, matte shot-blasted

19.76 €

13.83 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel12250EP, electropolished

15.42 €

10.79 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel12250GS, matte shot-blasted

24.60 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel16160EP, electropolished

19.46 €

13.62 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel16160GS, matte shot-blasted

26.74 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel16200EP, electropolished

22.14 €

15.50 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel16200GS, matte shot-blasted

30.26 €

21.18 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel16250EP, electropolished

24.08 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel16250GS, matte shot-blasted

32.92 €

23.04 €

1 Available Same day

Stock

[Stainless Steel] NI-Stainless Steel16300EP, electropolished

26.34 €

1 Available 7 Days [Stainless Steel] NI-Stainless Steel16300GS, matte shot-blasted
