SMC

Digital Pressure Switch, Built-In Regulator Type, ISE35 Series

Digital Pressure Switch, Built-In Regulator Type, ISE35 Series

Przestroga

  • See catalog for specification details.
  • Product pictures are representations. CAD data is not supported for some model numbers.

Numer części:

Znaleziono następującą liczbę niepotwierdzonych proponowanych produktów: 60.
Ilość:

Informacje o produkcie

Specifications of Digital Pressure Switch (Built-in Regulator Type) ISE35 Series

External appearance of digital pressure switch (built-in regulator type)

External appearance of digital pressure switch (built-in regulator type)

Lead entry specification ISE35-N (Wiring bottom entry)

Lead entry specification ISE35-N (Wiring bottom entry)

Lead entry specification ISE35-R (Wiring top entry)

Lead entry specification ISE35-R (Wiring top entry)

Option 1: ISE35-□-□-□L (Lead with connector [2 m in length])

Option 1: ISE35-□-□-□L (Lead with connector [2 m in length])

Option 2: ISE35-□-□-□□A (AR/AW Series installation kit)

Option 2: ISE35-□-□-□□A (AR/AW Series installation kit)

Option 2: ISE35-□-□-□□B (ARM10/11 Series mounting kit)

Option 2: ISE35-□-□-□□B (ARM10/11 Series mounting kit)

Applicable Series

A product series that this product can be installed on.

Product series nameProduct series model
F.R.L. combinationAC20・AC25・AC30・AC50・AC55・AC60
AC20A・AC30A・AC40A・AC50A・AC60A
AC20B・AC25B・AC30B・AC50B・AC55B・ AC60B
AC20C・AC25C・AC30C・AC40C
AC20D・AC30D・AC40D
RegulatorAR20 (K)・AR25 (K)・AR30 (K)・AR40 (K)・ AR50 (K)・AR55 (K)・AR60 (K)
Filter RegulatorAW20 (K)・AW30 (K)・AW40 (K)・AW60 (K)
Mist separator
Regulator		AWM20・AWM30・AWM40
Micro mist separator
Regulator		AWD20・AWD30・AWD40
Small manifold
Regulator		ARM10・ARM11
Direct acting precision regulatorARP20 (K)・ARP30 (K)・ARP40 (P)

Model Number Notation

Output specifications

  • 25: NPN output
  • 65: PNP output

Unit specifications

  • Blank: With unit switching function * 1
  • M: SI unit fixed * 2
  • P: Pressure unit: psi (default) with unit switching function * 1
  1. * 1Under the New Measurement Act of Japan, units with the unit switching function cannot be used in Japan.
  2. * 2Fixed unit: MPa

Specifications

ModelISE35
Rated pressure range0 to 1 MPa
Display / Set pressure range-0.1 to 1 MPa
Withstand pressure1.5 MPa
Display / Minimum set unit0.01 MPa
FluidAir, non-corrosive gases, nonflammable gas
Power supply voltage12 to 24 V DC ± 10%, ripple (p-p) 10% or less (With reverse connection protection)
Current Consumption55 mA or less (At no load)
Switch outputNPN or PNP open collector output, 1 output
-Maximum load current80 mA
Maximum applied voltage30 V (at NPN output)
Residual voltage1 V or less (with load current of 80 mA)
Response Time1s (0.25, 0.5, 2, 3s selection)
Short-circuit protectionYes
Repeatability±1%F.S
HysteresisHysteresis modeAdjustable (can be set from 0)
Window Comparator Mode
Display3-digit 7-segment display, 2-color display (red/green) Linkable with switch
Display accuracy±2% F.S. ±1 digit (At 25°C ± 3°C)
Indicator lightOUT: Lights when ON (Green)
EnvironmentProtective EnclosureIP40
Operating temperature range-5 to 50℃ (No condensation or freezing)
Lead wire with connector
(Option: For L)		Oil-resistant cabtire cord
3-core ø3.4 (diameter: 3.4 mm) 2 m
Conductor cross-sectional area: 0.2 mm^2 (AWG25)
Insulator outer diameter: 1.16 mm
WeightApprox. 14 g (main unit only) Approx. 38 g (Including lead wire with connector)
StandardsCE UL／CSA (E216656)

Internal Circuit and Connection

-25 NPN (1 Output)

-25 NPN (1 Output)

-65 PNP (1 Output)

-65 PNP (1 Output)

Dimensions



(Units: mm)



Dimensional drawing of digital pressure switch (Built-in regulator type)

Dimensional drawing of digital pressure switch (Built-in regulator type)

Option 1: Dimensional drawing of lead wire with connector

Option 1: Dimensional drawing of lead wire with connector

  • *See the SMC catalog for specification details.
  • *The product image is a representative image only.

Lista numerów części

Liczba pozycji
  • 1
    • Numer części
    ISE35-N-25
    ISE35-N-25-A
    ISE35-N-25-B
    ISE35-N-25-L
    ISE35-N-25-LA
    ISE35-N-25-LB
    ISE35-N-25-M
    ISE35-N-25-MA
    ISE35-N-25-ML
    ISE35-N-25-MLA
    ISE35-N-25-P
    ISE35-N-25-PL
    ISE35-N-25-PLA
    ISE35-N-65
    ISE35-N-65-A
    ISE35-N-65-B
    ISE35-N-65-L
    ISE35-N-65-LA
    ISE35-N-65-LB
    ISE35-N-65-LB-X501
    ISE35-N-65-M
    ISE35-N-65-MA
    ISE35-N-65-MB
    ISE35-N-65-ML
    ISE35-N-65-MLA
    ISE35-N-65-MLB
    ISE35-N-65-P
    ISE35-N-65-PA
    ISE35-N-65-PB
    ISE35-N-65-PL
    ISE35-N-65-PLA
    ISE35-N-65-PLB
    ISE35-R-25
    ISE35-R-25-A
    ISE35-R-25-B
    ISE35-R-25-L
    ISE35-R-25-LA
    ISE35-R-25-LB
    ISE35-R-25-M
    ISE35-R-25-MA
    ISE35-R-25-ML
    ISE35-R-25-MLA
    ISE35-R-25-MLB
    ISE35-R-25-PLA
    ISE35-R-65
    ISE35-R-65-A
    ISE35-R-65-B
    ISE35-R-65-L
    ISE35-R-65-LA
    ISE35-R-65-LB
    ISE35-R-65-M
    ISE35-R-65-MA
    ISE35-R-65-ML
    ISE35-R-65-MLA
    ISE35-R-65-P
    ISE35-R-65-PL
    ISE35-R-65-PLA
    ZS-32-A
    ZS-32-C
    ZS-32-D

    Type

    Fluid Type

    Sensor/Monitor Configuration

    Output Method

    Fluid Characteristics

    Pressure Type

    No. of Outputs

    Power Supply Type

    Power Supply Voltage

    (V)

    Protective Structure

    Unit Specifications

    Lead Wire

    Custom-made Specifications

    Rated Pressure Range

    Details Type

    Option

    Pressure Setting Range

    Wiring Specifications
