Powerful Type Multi-Function FXS-PKE

Volume Discount

OSG

In addition to the conventional film properties, achieves coating having a very high oxidizing, high-speed processing.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Product specification
Part Numbers
Catalog

Data to be displayed: 30; 45; 60

Part Number
FXS-PKE-3XR0.2X60
FXS-PKE-3XR0.2X70
FXS-PKE-3XR0.5X60
FXS-PKE-3XR0.5X70
FXS-PKE-4XR0.2X70
FXS-PKE-4XR0.2X80
FXS-PKE-4XR0.5X70
FXS-PKE-4XR0.5X80
FXS-PKE-5-R0.2X90
FXS-PKE-5XR0.2X80
FXS-PKE-5XR0.5X80
FXS-PKE-5XR0.5X90
FXS-PKE-6XR0.5X90
FXS-PKE-6XR0.5X100
FXS-PKE-6XR1X90
FXS-PKE-6XR1X100
FXS-PKE-8XR0.5X100
FXS-PKE-8XR0.5X110
FXS-PKE-8XR1X100
FXS-PKE-8XR1X110
FXS-PKE-10-R0.5X100
FXS-PKE-10XR0.5X120
FXS-PKE-10XR1X100
FXS-PKE-10XR1X120
FXS-PKE-10XR2X100
FXS-PKE-10XR2X120
FXS-PKE-12XR0.5X110
FXS-PKE-12XR0.5X130
FXS-PKE-12XR1X110
FXS-PKE-12XR1X130
FXS-PKE-12XR2X110
FXS-PKE-12XR2X130
FXS-PKE-16XR1X140
FXS-PKE-16XR2X140
FXS-PKE-16XR3X140
FXS-PKE-20XR1X160
FXS-PKE-20XR2X160
FXS-PKE-20XR3X160

Standard Unit Price	Minimum order quantity	Volume Discount	Standard Shipping Days ?	Blade diameter (D) (φ)	R Size (mm)	Blade length (ℓ) (mm)	Overall Length (L) (mm)	Shank diameter (d) (mm)	Underneck length (ℓ1) (mm)	Tool No.
95.20 €	1		6 Days	3	0.2	5	60	6	9	8547803
109.40 €	1	Available	6 Days	3	0.2	5	70	6	15	8547853
95.20 €	1	Available	6 Days	3	0.5	5	60	6	9	8548003
109.40 €	1		6 Days	3	0.5	5	70	6	15	8548053
98.20 €	1	Available	6 Days	4	0.2	6	70	6	12	8547804
112.90 €	1		6 Days	4	0.2	6	80	6	20	8547854
98.20 €	1	Available	15 Days	4	0.5	6	70	6	12	8548004
112.90 €	1		6 Days	4	0.5	6	80	6	20	8548054
131.70 €	1	Available	6 Days	5	0.2	8	90	6	25	8547855
114.70 €	1	Available	6 Days	5	0.2	8	80	6	15	8547805
114.70 €	1	Available	6 Days	5	0.5	8	80	6	15	8548005
131.70 €	1	Available	6 Days	5	0.5	8	90	6	25	8548055
125.70 €	1	Available	6 Days	6	0.5	9	90	6	18	8548006
143.60 €	1		6 Days	6	0.5	9	100	6	30	8548056
138.10 €	1		6 Days	6	1	9	90	6	18	8548206
143.60 €	1		6 Days	6	1	9	100	6	30	8548256
157.00 €	1	Available	6 Days	8	0.5	12	100	8	24	8548008
179.30 €	1	Available	6 Days	8	0.5	12	110	8	40	8548058
157.00 €	1	Available	6 Days	8	1	12	100	8	24	8548208
179.30 €	1	Available	6 Days	8	1	12	110	8	40	8548258
187.80 €	1		6 Days	10	0.5	15	100	10	30	8548010
219.90 €	1	Available	6 Days	10	0.5	15	120	10	50	8548060
187.80 €	1	Available	6 Days	10	1	15	100	10	30	8548210
219.90 €	1	Available	6 Days	10	1	15	120	10	50	8548260
196.70 €	1		6 Days	10	2	15	100	10	30	8548610
219.90 €	1		6 Days	10	2	15	120	10	50	8548660
258.40 €	1		6 Days	12	0.5	18	110	12	36	8548012
277.50 €	1		6 Days	12	0.5	18	130	12	60	8548062
258.40 €	1	Available	6 Days	12	1	18	110	12	36	8548212
277.50 €	1		6 Days	12	1	18	130	12	60	8548262
258.40 €	1		6 Days	12	2	18	110	12	36	8548612
277.50 €	1		6 Days	12	2	18	130	12	60	8548662
291.42 €	1		6 Days	16	1	24	140	16	48	8548216
291.42 €	1		6 Days	16	2	24	140	16	48	8548616
291.42 €	1		6 Days	16	3	24	140	16	48	8548816
442.00 €	1		6 Days	20	1	30	160	20	60	8548220
442.00 €	1		6 Days	20	2	30	160	20	60	8548620
442.00 €	1		6 Days	20	3	30	160	20	60	8548820

Products homepage

Basic information

work material	General steel / Quenched and tempered steel / High hardness steel –HRC55 / High hardness steel –HRC60 / Stainless Steel / Cast Iron / Titanium	Number of flutes(sheet)	4	Type	Radius
Machining Application	Plane / Side / Curved surface	Coating	TiAlN	Torsion Angle (θ)	High Helix (45˚ to 60˚)
Surface Treatment	FX

Configure

38Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Blade diameter (D)(φ)
3

4

5

6

8

10

12

16

20
Clear
R Size(mm)
0.2

0.5

1

2

3
Clear
Blade length (ℓ)(mm)
5

6

8

9

12

15

18

24

30
Clear
Overall Length (L)(mm)
60

70

80

90

100

110

120

130

140

160
Clear
Shank diameter (d)(mm)
6

8

10

12

16

20
Clear
Underneck length (ℓ1)(mm)
9

12

15

18

20

24

25

30

36

40

48

50

60
Clear
Tool No.
8547803

8547804

8547805

8547853

8547854

8547855

8548003

8548004

8548005

8548006

8548008

8548010

8548012

8548053

8548054

8548055

8548056

8548058

8548060

8548062

8548206

8548208

8548210

8548212

8548216

8548220

8548256

8548258

8548260

8548262

8548610

8548612

8548616

8548620

8548660

8548662

8548816

8548820
Clear
Type
- FXS-PKE
