AS-Interface AirBox

Basic Attributes

• Number of Inputs and Outputs

  • Number of digital inputs: 2; Number of pneumatic outputs: 1
  • Number of digital inputs: 2; Number of pneumatic outputs: 2
  • Number of digital inputs: 4; Number of pneumatic outputs: 1
  • Number of digital inputs: 4; Number of pneumatic outputs: 2

  Clear

• Pneumatic System

  • 1 x 4/2-way seat valve
  • 1 x 5/2-way slide valve (free from overlapping)
  • 1 x 5/2-way slide valve (free from overlapping); bistable
  • 1 x 5/3-way slide valve (free from overlapping); middle position blocked
  • 2 x 3/2-way seat valves
  • 2 x 3/2-way slide valves (free from overlapping)

  Clear

• Protection

  • IP 50
  • IP 65
  • IP 65; IP 67
  • IP 67

  Clear

• Operating Pressure Range(bar)

  • 2-8
  • 3-8

  Clear

• Air Flow at 6/0 Bar(l/min)

  • 500
  • 550
  • 700

  Clear

• Air Flow at 6/5 Bar(l/min)

  • 350
  • 400
  • 500

  Clear

• Tube Fittings(mm)

  • 8

  Clear

• Tube Fittings

  • Legris LF 3000/8
  • Legris LF 3000/8 / LF 3000/4

  Clear

• Materials

  • Housing: PBT; metal parts: stainless steel (1.4305 / 303); Sealing: FKM
  • PA; POM; piercing contacts: CuSn6 nickel-plated and tin-plated
  • PBT

  Clear

• Application

  • AS-i ATEX module
  • Field installation

  Clear

• Additional Voltage Supply(V)

  • 18-30 DC (to PELV)
  • 18-30 DC (to PELV) (required)

  Clear

• Permissible Compressed Air

  • filtered (5 µm); lubricated (ISO-VG10) or not lubricated
  • non-lubricated compressed air class 6-3-1; lubricated compressed air class 6-3-4

  Clear

• Ambient Temperature(°C)

  • -10-55
  • -10-50
  • 0-55

  Clear

• Operating Pressure Range(MPa)

  • 0.2-0.8
  • 0.3-0.8

  Clear

• Medium Temperature(°C)

  • -10-50

  Clear

• Exhaust

  • exhaust can be discharged through tube connection
  • integrated exhaust

  Clear

• Type of Mounting

  • quick mounting
  • screw mounting

  Clear

• Max. Current Consumption from AS-I(mA)

  • 150
  • 165
  • 170
  • 180
  • 280
  • 300

  Clear

• Dimensions(mm)

  • 45 x 80 x 46

  Clear
