Device Stands - Compact Flange(Lista numerów części: str. 2)

■Sets (Posts + Brackets)

Type		Post		Bracket		Accessory
Solid	Hollow	Material Hardness	Surface Treatment	Material	Surface Treatment	Solid	Hollow
FSBNM	FSBAM	EN 1.1191 Equiv. Induction Hardened	Electroless Nickel Plating	EN 1.1191 Equiv.	LTBC Plating	Set Screw	Set Screw Cap (P.2143)
MFSBN	MFSBA	EN 1.1191 Equiv.
KFSBN	KFSBA		Black Oxide
MSFSBN	MFSBB	EN 1.4301 Equiv.	-
FSTNM	FSTAM	EN 1.1191 Equiv. Induction Hardened	Electroless Nickel Plating	EN 1.1191 Equiv.	Electroless Nickel Plating
MFSTN	MFSTA	EN 1.1191 Equiv.
MSFSTN	MFSTB	EN 1.4301 Equiv.	-
KBFSBN	KBFSBA	EN 1.1191 Equiv.	Black Oxide	EN 1.1191 Equiv.	Black Oxide
MSFSS	MFSSS	EN 1.4301 Equiv.	-	EN 1.4301 Equiv.	-

* Case Induction Hardened (Post): 58HRC ~, Depth 1.0 ~ 1.5
* For Posts for Stands only, see P.2143, 2144.
* There may be no electroless nickel plating and black oxide at ends and grooves of posts.

■Bracket only

Type	Material	Surface Treatment	Accessory
MFSBF	EN 1.1191 Equiv.	LTBC Plating	Set Screw
MFSTF		Electroless Nickel Plating
MFSLF		Black Oxide
MFSS	EN 1.4301 Equiv.	-

Part Number						L 1mm Increment	A	B	F	D1	H	T	ℓ	b	M	(d)
Type			D	Postsg6	BracketsH7
set		Bracket only	*16	-0.004 -0.012	+0.012 0	50~150	33	18	23	14	20	6	12.5	4.5	M4	-
			8	-0.005 -0.014	+0.015 0	50~200	38	20	26	16	30	8	15	4.5	M4	-
(Solid) FSBNM MFSBN KFSBN MSFSBN FSTNM MFSTN MSFSTN KBFSBN MSFSS	(Hollow) FSBAM MFSBA KFSBA MFSBB FSTAM MFSTA MFSTB KBFSBA MFSSS	MFSBF MFSTF MFSLF MFSS	10	-0.005 -0.014	+0.015 0	50~250	40	22	28	18	35	8	18	4.5	M4	6
			12	-0.006 -0.017	+0.018 0	50~300	46	24	32	20	35	8	18	5.5	M4	6
			15	-0.006 -0.017	+0.018 0	75~350	56	29	40	25	40	8	20	6.6	M5	10
			20	-0.007 -0.020	+0.021 0	75~400	63	34	46	30	45	10	25	6.6	M5	11.7
			25	-0.007 -0.020	+0.021 0	75~450	78	41	56	37	50	10	30	9	M6	15.2
			30	-0.007 -0.020	+0.021 0	100~450	82	46	62	42	60	10	30	9	M6	16

*1. D6 is available for FSTNM, MFSBN, MFSTN, MSFSTN, MFSBF and MFSTF only. [ ! ]Hollow posts are available from D10. [ ! ]Refer to the price list for availability of brackets as a separate item.
